How do Compression Garments Work?

Compression Garment

To understand how compression garments work, you must first understand how they are made.

How Compression Garments Are Made

Circular knit is made with a machine that knits the fabric in a continuous circle (tube); the weight is “light” and the fabric is thin.

  • Tube shaped
  • Thin
  • A tendency to curl down the limb
  • Pinch (especially in the creases; ankle, behind the knee) causing pain
  • A long stretch, lower containment


Flat knit is made with a machine that knits the fabric in sheets (flat).  Flat knit is thick and made with two rows of needles that are on a 90-degree angle opposite of each other. If this is hard to picture think about how your grandmother made a blanket or sweater with two needle-sticks.

  • Fit to the patient
  • Thick
  • Lays flat on the limb
  • Less likely to pinch. Will lay flat over the creases
  • Short stretch, higher containment


How Compression Garments Work

Compression garments work by providing external gradient compression to a limb or limbs with a variety of different materials, knitting styles, and compression levels. Their common goal is to maintain swelling in a limb affected by lymphedema. Without these vital garments, the limb will continue to swell causing pain, fibrosis, open wounds, infection, hospitalization, and possible death.  This is why it is so important that we get educated on the different compression garments and how to select the correct one. Selecting the correct garment with these uniques qualities will lead to better patient outcomes and reduce wasted time and money for the patient, hospitals, and insurers.

If you are a clinician or a patient with lymphedema or any other swelling disorder, it is very important that you understand the differences between circular knit and flat knit.

Circular Knit vs. Flat Knit

It is a common mistake to be prescribed circular knit because these garments come in ready-to-wear sizes, can be easily obtained, and are cheap. However, whoever invented the phrase “You get what you pay for” was probably speaking specifically about circular knit or ready-to-wear compression garments.

Circular knit is intended for mild edema. For example, if a patient has mild lymphedema (stage 0), circular knit might work for a short period of time but swelling could occur causing pinching at the joints (ankle, wrist, behind the knee) due to the lack of proper structure and containment. This can lead to increased swelling, fibrosis, pitting edema, and possibly cellulitis in the affected limb.

Flat knit compression garments are short-stretch with better containment without pinching. This allows them to be more comfortable and easier to get on. Flat-knit compression garments are custom-made so they need to be measured by a certified fitter. Flat knit are custom made to fit the limb like a second skin. For example, a custom flat-knit knee-high compression garment requires 14 measurements while circular-knit only needs three measurements.

Pain is never a normal thing when a patient is wearing the correct compression garment. Always remember, pain and swelling mean you received the wrong compression garment.  If you received a compression garment that is easier to apply, is comfortable, and has great containment, that means you received the correct compression garment.


Ready-to-wear, circular-knit compression garments are recommended the most because of the low cost assorted with them. A typical ready-to-wear, circular-knit compression garment costs around $50 at a local pharmacy while a custom, flat-knit compression garments can cost on average $400-$500 per pair. Luckily, custom compression garments are covered by most private insurances, the Veterans Administration, and most state Medicaid plans but not by Medicare. A pair of custom-made knee highs will last an average patient a minimum of 6 months of wear and tear.  At $500 a pair for custom, that averages out to $2.77 a day to maintain your swelling. This will help keep your limb(s) from swelling to a point where more therapy is required which will cost much more than $500.

Lymphedema is a chronic disease with no known cure.  However, with proper lymphedema therapy and the correct compression garment, you can maintain healthy limbs.

To summarize, if you are a patient with lymphedema or a clinician trying to assist your patient in a correctly fitting compression garment, prescribing flat-knit compression garments will give the patient a much greater chance of being successful in managing their swelling independently.
